Strike, dip, and rake directions in focal mechanism
Vincent S. Cronin wrote A Primer on Focal Mechanism Solutions for Geologists (2010). My interest in his work is in his descriptions of fault vectors and angles. I need to use these standard names if I wish to write a paper on Focal Mechanism of Earthquakes.
Based on Cronin's diagram in p. 6, the reference strike, which we shall denote by $\mathbf e_{strike}$ appears to be the direction of the fault line as seen from a drone camera flying overhead high above the fault. The dip vector, which we shall denote by $\mathbf e_{dip}$, is a vector perpendicular to the reference strike $\mathbf e_{strike}$ and lies along the fault plane. The direction of $\mathbf e_{dip}$ is downward along the fault in Cronin. In this way, if we define the rake $\mathbf e_{rake}$ as the direction of the movement of the one side of the fault, then $\mathbf e_{rake}$ can be expressed as a rotation of $\mathbf e_{strike}$ about $\mathbf e_{dip}\times\mathbf e_{strike}$ by an angle $\theta_{rake}$, which is positive if the rotation is counterclockwise and negative if clockwise, following the right hand rule. These considerations results to the following expression for the rake direction $\mathbf e_{rake}$:
\begin{equation}
\mathbf e_{rake} = \mathbf e_{strike}\cos\theta_{rake}  \mathbf e_{dip}\sin\theta_{dip}.
\end{equation}
But even then, there is an uncertainty in the definition of the strike direction $\mathbf e_{strike},$ since $\mathbf e_{strike}$ can also be the initial definition. Perhaps, the strike direction should be defined as that which makes an acute angle with respect to the north direction.
Based on Cronin's diagram in p. 6, the reference strike, which we shall denote by $\mathbf e_{strike}$ appears to be the direction of the fault line as seen from a drone camera flying overhead high above the fault. The dip vector, which we shall denote by $\mathbf e_{dip}$, is a vector perpendicular to the reference strike $\mathbf e_{strike}$ and lies along the fault plane. The direction of $\mathbf e_{dip}$ is downward along the fault in Cronin. In this way, if we define the rake $\mathbf e_{rake}$ as the direction of the movement of the one side of the fault, then $\mathbf e_{rake}$ can be expressed as a rotation of $\mathbf e_{strike}$ about $\mathbf e_{dip}\times\mathbf e_{strike}$ by an angle $\theta_{rake}$, which is positive if the rotation is counterclockwise and negative if clockwise, following the right hand rule. These considerations results to the following expression for the rake direction $\mathbf e_{rake}$:
\begin{equation}
\mathbf e_{rake} = \mathbf e_{strike}\cos\theta_{rake}  \mathbf e_{dip}\sin\theta_{dip}.
\end{equation}
But even then, there is an uncertainty in the definition of the strike direction $\mathbf e_{strike},$ since $\mathbf e_{strike}$ can also be the initial definition. Perhaps, the strike direction should be defined as that which makes an acute angle with respect to the north direction.
Assistant Professor, Department of Physics, Ateneo de Manila University. Program Head, Upper Atmosphere Dynamics, Manila Observatory.
15 November 2017
Trend and plunge angles of faults
In his web page on Data in Structural Geology, W. F. Waldron of University of Alberta defined fault directions in terms of the trend angle $T$ and the plunge angle $P$. Here, we shall use his angular notations, but rewrite his coordinate system in vector form and redraw his diagram.
To define the direction of the trendplunge unit vector $\mathbf e_{TP}$, we first define a righthanded coordinate system $\mathbf e_1$, $\mathbf e_2$, and $\mathbf e_3$ for East, North, and Up directions. The plunge angle $P$ would then be the angle made by $\mathbf e_{TP}$ with the EastNorth plane. In other words,
\begin{equation}
\mathbf e_{TP}\cdot\mathbf e_3 = \cos(90^\circP)=\sin P\equiv n,
\end{equation}
so that the projection onto the EastNorth Plane would then be $\cos P$. Next, we define the trend angle $T$ as the clockwise angle from North to East that the $\cos P$ projection of $\mathbf e{TP}$ makes with the Northward axis $\mathbf e_2$. This allows us to compute the other direction cosines along $\mathbf e_1$ and $\mathbf e_2$:
\begin{align}
\mathbf e_{TP}\cdot\mathbf e_1 &= \cos P\sin T\equiv \ell,\\
\mathbf e_{TP}\cdot\mathbf e_2 &= \cos P\cos T\equiv m.
\end{align}
Combining these relations, we obtain the expression for the vector $\mathbf e_{TP}$ in Eastward, Northward, and Upward coordinates:
\begin{align}
\mathbf e_{TP} &= \mathbf e_1\cos P\sin T + \mathbf e_2 \cos P\cos T \mathbf e_3\sin P\nonumber\\
&=\ell\mathbf e_1 + m\mathbf e_2 + n\mathbf e_3.
\end{align}
To define the direction of the trendplunge unit vector $\mathbf e_{TP}$, we first define a righthanded coordinate system $\mathbf e_1$, $\mathbf e_2$, and $\mathbf e_3$ for East, North, and Up directions. The plunge angle $P$ would then be the angle made by $\mathbf e_{TP}$ with the EastNorth plane. In other words,
\begin{equation}
\mathbf e_{TP}\cdot\mathbf e_3 = \cos(90^\circP)=\sin P\equiv n,
\end{equation}
so that the projection onto the EastNorth Plane would then be $\cos P$. Next, we define the trend angle $T$ as the clockwise angle from North to East that the $\cos P$ projection of $\mathbf e{TP}$ makes with the Northward axis $\mathbf e_2$. This allows us to compute the other direction cosines along $\mathbf e_1$ and $\mathbf e_2$:
\begin{align}
\mathbf e_{TP}\cdot\mathbf e_1 &= \cos P\sin T\equiv \ell,\\
\mathbf e_{TP}\cdot\mathbf e_2 &= \cos P\cos T\equiv m.
\end{align}
Combining these relations, we obtain the expression for the vector $\mathbf e_{TP}$ in Eastward, Northward, and Upward coordinates:
\begin{align}
\mathbf e_{TP} &= \mathbf e_1\cos P\sin T + \mathbf e_2 \cos P\cos T \mathbf e_3\sin P\nonumber\\
&=\ell\mathbf e_1 + m\mathbf e_2 + n\mathbf e_3.
\end{align}
